DPS 3000

DPS 3000
Profesionálny digitálny výkonový zosilňovač triedy HD, 2 x 1 200 W RMS / 4 ohm, 2 x 800W/ 8 ohm, vstupné konektory XLR, výstupné konektory Speakon, 19"/2U, 14kg

Cena: 865,00 € bez DPH 26 058,99 Sk bez DPH
1 038,00 € s DPH 31 270,79 Sk s DPH

DATA Library       Stránka výrobcu       Katalogový list SK



Features
  • Fast response and low distortion
  • Easy to configure in stereo / mono / bridge modes
  • Extensive protective circuits ensure high reliability and operating safety
  • Front panel signal / clip / protect LED indicators
  • Minimum load impedance (stereo / mono): 2 Ohm
  • XLR input connectors
  • SPEAKON output connectors
  • Switchable limiter
  • PFC (Power Factor Corrector)
  • 2 unit 19" rack, low weight for easy transportation
Amplifier Specifications
  • Power output stereo 2Ω: 2 x 1700 W rms
  • Power output stereo 4Ω: 2 x 1200 W rms
  • Power output stereo 8Ω: 2 x 800 W rms
  • Power output bridged 4Ω: 3400 W rms
  • Power output bridged 8Ω: 2400 W rms
  • Frequency Response -3 dB: 20 Hz ÷ 20 kHz
  • Signal/noise rate: 108 dB
  • Damping factor: > 1000
  • Slew rate: 55V/μS
Input Section
  • Input connector: xlr
  • Input sensitivity: 1.4 dBm/V RMS
Output Section
  • Output connector: Speakon
System Parameters
  • Cooling: Temperature-controlled fan
  • Protections: Temp., DC, RFI, short-circuit
  • Voltage gain: 32 – 26 dB
  • Amplifier class: HD
Power Requirements
  • Operating voltage: 90 ÷ 245 V (50 / 60 Hz) V ~ Hz
  • Power consumption: SMPS W
  • Power factor (cos φ): 0.95 from 200 W to full power
Physical Specifications
  • Height: 88/3.4 mm/inch
  • Width: 482/18,9 mm/inch
  • Depth: 420/16.5 mm/inch
  • Net Weight: 14/30.8 kg/lbs
